A30
- Compact plastic housing
- Flexible assembly
- Wide temperature range
- Max. measuring length : 0,6 m
- Speed : 0,8 m/s
- max. linearity : ±0,35 %
Add to wishlist
Miniature actuated encoder – ideal for simple applications.
The A30 draw-wire encoder with analog output impresses with its miniaturized design. It is available with potentiometer, voltage, or current output.
Technical Data
| Mechanical | |
|---|---|
| Measuring system | Draw-wire encoders |
| Measuring length | 0.3 m 0.6 m |
| Speed | 0,8 m/s |
| Dimension | 28 mm x 41 mm x 33 mm |
| Connection types | Radial cable |
| Working temperature | -10 °C … +80 °C |
| Protection level | IP50 |
| Weight | 60 g |
| Electrical | |
|---|---|
| max. linearity | ±0,35 % |
| Interfaces | Analog 0…10 V Analog 4–20 mA Potentiometer output |
| Power supply | 15…28 V DC |
- Measuring length up to 600 mm.
- For applications with a low traversing speed.
- Easy to install.
- Housing of reinforced plastic.
Benefits
Miniaturized and simple
Downloads
| Data sheet | |
|---|---|
|
A30 PDF ∼ 494,7 KB | 02.2023 |
Download |
| Declaration of conformity | |
|---|---|
|
A30 / A40 / A41 / B75 / C105 CE Multilingual: German, English, French |
Download |
| Operation Manual | |
|---|---|
|
A30 Multilingual: German, English |
Download |
| Mechanical CAD / STEP | |
|---|---|
|
A30 ZIP ∼ 240,7 KB | 02.2017 |
Download |
- Installation angle (anodized aluminum)
- Guide pulley (plastic POM)
- Ball bearing (Type 696-2R5)
- 2 x countersunk screws for side fixing
- 2 x Allen screws for fixing on a flat surface
Accessories
 |
Guide pulley With guide pulleys, linear movements can also be directed around obstacles. This not only increases their flexibility but can also compensate for installation tolerances. Idler pulleys can also act to clean off dirt and break ice. Technical data: Scope of delivery: 8.0000.7000.0045 |
