Draw wire encoder – suitable for the highest requirements.
The B80 draw-wire encoder can be used up to a measuring length of 3 meters.
This draw wire can be combined with the proven Kübler Sendix encoders with incremental or absolute interface as well as with analog sensors.
| Mechanical | |
|---|---|
| Measuring system | Draw-wire encoders |
| Measuring length | 1 m 2 m 3 m |
| Speed | 10 m/s |
| Dimension | 80 mm x 80 mm x 144 mm |
| Working temperature | -20 °C … +90 °C |
| Protection level | IP65 |
| Weight | 750 g |
| Electrical | |
|---|---|
| max. linearity | ±0,02 % |
| Interfaces | Analog 0…10 V Analog 4–20 mA EtherNet/IP CANopen EtherCAT Push Pull TTL / RS422 SAE J1939 SinCos Potentiometer output PROFIBUS DP PROFINET IO SSI, Binary SSI, Gray BiSS IO-Link |
| Power supply | 12…30 V DC |
Robust
Versatile
| Data sheet | |
|---|---|
|
B80 PDF ∼ 1,2 MB | 02.2023 |
Download |
| Installation manual | |
|
Safety Advice for Draw-wire encoders Multilingual: German, English, French, Italian |
Download |
| Manual | |
|
A50 / B80 / C120 / D135 PDF ∼ 932,0 KB | 09.2017 |
Download |
| Mechanical CAD / STEP | |
|
B80 ZIP ∼ 12,2 MB | 01.2015 |
Download |
| Declaration of conformity | |
|
A50 / B80 / C120 / D135 CE Multilingual: German, English, French |
Download |
| Device file | |
|---|---|
|
Sendix 58×8 CANopen ZIP ∼ 63,9 KB | 02.2018 |
Download |
|
Sendix 58×8 EtherCAT ZIP ∼ 42,7 KB | 05.2017 |
Download |
|
Sendix 58×8 PROFIBUS ZIP ∼ 35,8 KB | 08.2017 |
Download |
|
Sendix 58×8 PROFINET GSDML ZIP ∼ 15,2 KB | 09.2016 |
Download |
|
Sendix F58x8 CANopen ZIP ∼ 11,2 KB | 10.2014 |
Download |
|
Sendix F58xx – Singleturn EtherNet/IP ZIP ∼ 15,0 KB | 01.2021 |
Download |
|
Sendix F58xx – Multiturn EtherNet/IP ZIP ∼ 15,0 KB | 01.2021 |
Download |
|
Sendix M58x8 MT CANopen ZIP ∼ 678,9 KB | 12.2022 |
Download |
 |
Guide pulley With guide pulleys, linear movements can also be directed around obstacles. This not only increases their flexibility but can also compensate for installation tolerances. Idler pulleys can also act to clean off dirt and break ice. Technical data:
Scope of delivery:
8.0000.7000.0045 |
Mechanical CAD / STEP 8.0000.7000.0045 |
Download |
 |
Extension cable steel With extension cables, the actual measuring range can be used without any loss of resolution. We offer numerous extension cables in our portfolio for this purpose.
|
 |
M12 Connector with cable , Preassembled cable set
|
Female connector 5-pin PVC Ø 5,5 mm ± 0,2 mm 5 x 0,25 mm2 |
05.00.6081.2211.XXXM
|
Data sheet M12 cordset, PVC, socket, 5-pin, A-coded, open end |
Download |
 |
M12 Connector , Field-wireable connector
|
Female connector 5-pin |
05.B-8151-0/9
|
Data sheet M12 socket, 5-pin |
Download |
 |
M12 Connector , Field-wireable connector
|
Female connector 5-pin |
05.B-8251-0/9
|
Data sheet M12 socket, angled, 5-pin, A-coded |
Download |
 |
M12 Connector , Field-wireable connector
|
Female connector 5-pin |
8.0000.5116.0000
|
Data sheet M12 socket, 5-pin, A-coded |
Download |
