B75
- Flexible assembly
- Integrated water drain holes
- Encoder freely selectable
- 360° encoder adjustment
- Max. measuring length : 3 m
- Speed : 0,8 m/s
- max. linearity : ±0,35 %
Add to wishlist
Draw wire encoder – the flattest on the market.
The B75 draw-wire encoder can be used up to a measuring length of 3 meters.
These draw-wire mechanics may be combined with the proven Kübler Sendix encoders with incremental or absolute interface, as well as with analog sensors, which are also available in redundant version.
Technical Data
| Mechanical | |
|---|---|
| Measuring system | Draw-wire encoders |
| Measuring length | 3 m |
| Speed | 0,8 m/s |
| Dimension | 78 mm x 78 mm x 55 mm |
| Working temperature | -40 °C … +85 °C |
| Protection level | IP65 |
| Weight | 500 g |
| Electrical | |
|---|---|
| max. linearity | ±0,35 % |
| Interfaces | Analog 0…10 V Analog 4–20 mA EtherNet/IP CANopen EtherCAT Push Pull TTL / RS422 SAE J1939 Potentiometer output PROFIBUS DP PROFINET IO SSI, Binary SSI, Gray BiSS IO-Link |
| Power supply | 15…28 V DC |
- Compact housing.
- Variable mounting possibilities.
- Low-wear wire exit.
- Closable ventilation and water drain holes.
- Scalable analog interface with limit switch function.
- Various fieldbus interfaces.
- Redundant Sensors.
Benefits
Compact and versatile
Downloads
| Data sheet | |
|---|---|
|
B75 PDF ∼ 1,1 MB | 02.2023 |
Download |
| Installation manual | |
|
Safety Advice for Draw-wire encoders Multilingual: German, English, French, Italian |
Download |
| Operation Manual | |
|
B75 Multilingual: German, English |
Download |
| Mechanical CAD / STEP | |
|
B75 ZIP ∼ 6,3 MB | 02.2017 |
Download |
| Device file | |
|---|---|
|
Sendix 58×8 CANopen ZIP ∼ 63,9 KB | 02.2018 |
Download |
|
Sendix 58×8 EtherCAT ZIP ∼ 42,7 KB | 05.2017 |
Download |
|
Sendix 58×8 PROFIBUS ZIP ∼ 35,8 KB | 08.2017 |
Download |
|
Sendix 58×8 PROFINET GSDML ZIP ∼ 15,2 KB | 09.2016 |
Download |
|
Sendix F58x8 CANopen ZIP ∼ 11,2 KB | 10.2014 |
Download |
|
Sendix F58xx – Singleturn EtherNet/IP ZIP ∼ 15,0 KB | 01.2021 |
Download |
|
Sendix F58xx – Multiturn EtherNet/IP ZIP ∼ 15,0 KB | 01.2021 |
Download |
|
Sendix M58x8 MT CANopen ZIP ∼ 678,9 KB | 12.2022 |
Download |
- Installation angle (anodized aluminum)
- Guide pulley (plastic POM)
- Ball bearing (Type 696-2R5)
- 2 x countersunk screws for side fixing
- 2 x Allen screws for fixing on a flat surface
Accessories
 |
Extension cable Paraleine With extension cables, the actual measuring range can be used without any loss of resolution. We offer numerous extension cables in our portfolio for this purpose.
|
||
|
Extension cable steel With extension cables, the actual measuring range can be used without any loss of resolution. We offer numerous extension cables in our portfolio for this purpose.
2 m 8.0000.7000.0033 |
||
 |
Guide pulley With guide pulleys, linear movements can also be directed around obstacles. This not only increases their flexibility but can also compensate for installation tolerances. Idler pulleys can also act to clean off dirt and break ice. Technical data: Scope of delivery: 8.0000.7000.0045 |
Mechanical CAD / STEP 8.0000.7000.0045 |
Download |
Cables and Connectors
 |
M12 Connector with cable , Preassembled cable set
|
Male connector 4-pin PUR Ø 6,5 mm ± mm 2 x 2 x 0,34 mm2 |
05.00.6031.4411.XXXM
|
Data sheet M12 cable satez, PUR, pin, 4-pin, D-coded, open end |
Download |
 |
M12 Connector with cable , Preassembled cable set
|
Female connector 5-pin PVC Ø 5,5 mm ± 0,2 mm 5 x 0,25 mm2 |
05.00.6081.2211.XXXM
|
Data sheet M12 cordset, PVC, socket, 5-pin, A-coded, open end |
Download |
 |
M12 Connector , Field-wireable connector
|
Female connector 5-pin |
05.B-8151-0/9
|
Data sheet M12 socket, 5-pin |
Download |
 |
M12 Connector , Field-wireable connector
|
Female connector 4-pin |
05.B8141-0
|
Data sheet M12 socket, 4-pin, A-coded |
Download |
 |
M12 Connector , Field-wireable connector
|
Female connector 4-pin |
05.B8241-0
|
Data sheet M12 socket, angled, 4-pin, A-coded |
Download |
 |
M12 Connector , Field-wireable connector
|
Male connector 4-pin |
05.BS8141-0
|
Data sheet M12 pin, 4-pin, A-coded |
Download |
 |
M12 Connector , Stainless steel V4A Field-wireable connector
|
Female connector 8-pin |
8.0000.5136.0000.V4A
|
Data sheet M12 socket, stainless steel V4A, 8-pin, A-coded |
Download |
 |
M12 Connector , Connectors Field-wireable connector
|
Female connector 4-pin |
8.0000.5202.0000
|
Data sheet M12 socket, 4-pin, S-coded |
Download |
